［Specifications］：

Image Sensor
Image Sensor	SONY 1/1.7"
Still Resolution	64 MP
Color Filter Type	Color
Shutter Type	Rolling shutter
Optical Size	1/1.7 inch
Output Format	JPEG/YUV/RGB/RAW10
Pixel Size	0.8 μm×0.8 μm
Sensor Active Area	9152(H) × 6944(V)
Frame Rate	1080p30,720p60 and 640×480p60/90
Video Modes (Camera Module)	9152×6944@2fps, 8000×6000@2.5fps, 4624×3472@7.6fps, 3840×2160@14.8fps, 2312×1736@26.7fps, 1920×1080@45fps
Lens
Lens Mount	Stock lens
Focus Type	PDAF + CDAF
FOV	84°(D)
F.NO	F1.8
E.F.L	5.1mm
Default Focus Range	8cm-∞
IR Sensitivity	Integral IR-cut Filter, visible light only
Electrical and Mechanical
Operating Voltage	5 V +/- 5%
Operating Temp.	32°F-158°F (0°C to 70°C)
Power Requirements	7.5W
Camera Board Size	24×25mm
Overall Size	99×70×37 mm
Functionality and Compatibility
Supported OS	Bookworm
Pre-installed Software	hailo-all rpicam-apps-hailo-postprocess opencv-python, libopencv-dev (C++ version) libcamera, rpicam-apps C++ essential tools (building environment) TensorFlow (Python)/ PyTorch camera-streamer, arducacm camera server
Supported Platform	Raspberry Pi 5

［Notes］：

• Tripod is not included in the package, please check UB0216 for additional purchase.／不包含三腳架，請查看UB0216另行購買。
• This product kit includes the Raspberry Pi 5 with 4GB of RAM and a 32GB SD card preloaded with OS and software. It is recommended to use only this platform.建議僅使用此平台。
• For optimal performance, we suggest using the official Raspberry Pi 27W power supply.我們建議使用 Raspberry Pi 官方 27W 電源。

• Arducam Pivistation 5

   Blog
• When Raspberry Pi AI Camera Meets Pivistation 5
• Conceiving Pivistation 5 – Early Stage Involvement Is Welcome!

［Pivistation 5 - Your All in one Raspberry Pi 5 Camera Kit］

影片：https://youtu.be/_g2NmdMfFQE?si=tqfZkJfA1GUnYrGX

Ｑ１：Who are supposed to be the users of Pivistation 5?

Any individual, research institution, established company or start-up with mid-high requirements of embedded vision performance is suitable to leverage Pivistation 5 as an efficient PoC tool.

Ｑ２：I am already a user of Arducam camera modules and they are running well, what’s the point of changing to Pivistation 5?

　　Pivistation 5 is specifically tailored for Raspberry Pi vision applications. Our professional team handles module adaptation, ensuring stability and saving users (esp. those who are less familiar with embedded vision hardware) effort in configuration. However, if your current setup with Arducam camera modules is performing well, there’s no need to switch. In addition, not all current or future models in the Pivistation 5 series have corresponding camera module products. For this part, you can directly use pivistation 5 to get a better experience.

Ｑ３：Which types of Raspberry Pi 5 are used for Pivistation 5 models?

A: The currently available Pivistation 5 models all house a Raspberry Pi 5 with 4GB RAM.

Ｑ４：Can I replace the Pi5 that comes with the product with another one?

It is recommended that you do not replace the original Pi5 in the product. This operation is only suitable for experienced users. Arducam will not be held responsible if damage occurs after replacement.

Ｑ５：Can I change the lenses of Pivistation 5 according to my project?

A: Some models of Pivistation 5 support lens replacement. To get the best results, it is recommended that you send emails to support@arducam.com to obtain our technical support before lens replacement.

Ｑ６：Is Pivistation 5 suitable for outdoor use?

A: The currently available Pivistation 5 models are primarily designed for indoor applications. Outdoor use, however, might be considered for future models by adding proper protection from environmental factors such as moisture and temperature fluctuations.

Ｑ７：What power source does Pivistation 5 require?

A: The working consumption of Pivstation 5 is 7.5W, and we recommend you use a 27W Type C power supply.

Q: Can I customize my Pivistation 5 order?

We are happy to hear your ideas about more Pivistaion 5 variations besides the running ones. For bulk potential orders, please email sales@arducam.com directly to discuss.
