產品說明0
※本產品原廠代理從國外進口，有些交期較長，下訂前請詢問！
Seeed XIAO ESP32S3 Sense 模組（113991115），支持Wi-Fi、藍牙5.0、OV2640相機、電池充電、麥克風
Seeed XIAO ESP32S3 Sense - 2.4GHz Wi-Fi, BLE 5.0, OV2640 camera sensor, digital microphone, 8MB PSRAM, 8MB FLASH, battery charge supported, rich Interface, IoT, embedded ML／2.4GHz Wi-Fi、BLE 5.0、OV2640 相機感應器、數位麥克風、8MB PSRAM、8MB 快閃記憶體、支援電池充電、豐富的介面、IoT、嵌入式ML
Seeed Studio XIAO ESP32S3 leverages dual-core ESP32S3 chip, supporting both Wi-Fi and BLE wireless connectivities, which allows battery charge. It integrates built-in camera sensor, digital microphone. It offers 8MB PSRAM, 8MB FLASH, and external SD card slot. All of these make it suitable for embedded ML, like intelligent voice and vision AI.／Seeed Studio XIAO ESP32S3 採用雙核心 ESP32S3 晶片，支援 Wi - Fi 和 BLE 無線連接，並允許電池充電。它整合了內建攝影機感應器、數位麥克風。它提供 8MB PSRAM、8MB 快閃記憶體和外部 SD 卡插槽。所有這些都使其適合嵌入式機器學習，例如智慧語音和視覺人工智慧。
【影片】：
Smallest Camera Module based on ESP32 S3 | XIAO ESP32S3 Sense
https://youtu.be/_wvuOsRgmt4?si=SU5EOcPIVK7lHeSS
【Part List】清單：
- Seeed Studio XIAO ESP32S3 (pin not included 模組 x1
- Antenna 天線 x1
- Plug-in camera sensor board 相機 X1
【注意】：Check five pieces of 7-pin male header compatible with Seeed Studio XIAO Series Board!
【正反面】：
【Features】：
- Flexible MCU Board：Incorporate the ESP32S3 32-bit, dual-core, Xtensa processor chip operating up to 240 MHz, mounted multiple development ports, Arduino / MicroPython supported
- Advanced Functionality：Detachable OV2640 camera sensor for 1600*1200 resolution, compatible with OV5640 camera sensor, integrating additional digital microphone／可拆卸 OV2640 攝影機感測器
- Great Memory for more Possibilities： Offer 8MB PSRAM and 8MB FLASH, supporting SD card slot for external 32GB FAT memory
- Outstanding RF performance： Support 2.4GHz Wi-Fi and BLE dual wireless communication, support 100m+ remote communication when connected with U.FL antenna
- Thumb-sized Compact Design： 21 x 17.8mm, adopting the classic form factor of XIAO, suitable for space-limited projects like wearable devices
- Pretrained Al model from SenseCraft AI for no-code deployment
［Note］：
XIAO SoM User Manual open-sources all hardware and software materials of XIAO, providing professional product design guidelines to help you accelerate ideas off the ground, streamline product design, providing a seamless experience from module selection to mass production. You can check here to see more info.／XIAO SoM使用手冊開源了XIAO所有硬體和軟體資料，提供專業的產品設計指南，幫助您加速創意落地、簡化產品設計，提供從模組選型到量產的無縫體驗。您可以在這裡查看更多資訊。
［Note］：
There are two additional GPIO on the plug-in camera sensor board linking to the microphone. If you want to apply these two external IO, the microphone should not be used at the same time. ／ 插入式攝影機感應器板上有兩個額外的 GPIO 連接到麥克風。如果要套用這兩個外部IO，麥克風不應該同時使用。
【Specification】：
【Application】：
- Image processing
- Speech Recognition
- Video Monitoring
- Wearable devices
- Smart Homes
- Health monitoring
- Education
- Low-Power(LP) networking
- Rapid prototyping
