B0287，Arducam IMX219 Camera 220度魚眼攝像頭模組，適用NVIDIA Jetson Nano、NX、Orin NX、AGX Orin
Arducam IMX219 Camera Module with fisheye lens for NVIDIA Jetson Nano/Xavier NX and NVIDIA Orin NX/AGX Orin
ＰＳ．本相機鏡頭不可更換，如需更換鏡頭，下單前請先詢問!!!
【Package Including／清單】
- 1pcs Arducam IMX219 Camera Module with fisheye lens for NVIDIA Jetson Board（模組改版，15P 改22P排線接口）
- 1pcs 0.5mm－15cm 22pin-22P FPC cable
- 1pcs 1.0mm－15cm 15pin-22pin FPC cable
This Arducam IMX219 camera module is mainly designed for NVIDIA® Jetson Nano/Xavier NX and also can be used on other hardware like ARM, DSP, FPGA, etc. The highlight of this camera is its wide field of view.
這款Arducam IMX219攝像頭模塊主要為NVIDIA® Jetson Nano/Xavier NX設計，也可用於其他硬件，如ARM、DSP、FPGA等。這款攝像頭的亮點在於其廣闊的視野。。
Currently, NVIDIA official has released the NVIDIA Jetson Orin series developer board. Based on it, we have also adapted the camera into NVIDIA Jetson Orin kernel.／目前，NVIDIA官方已經發布了NVIDIA Jetson Orin系列開發板。基於它，我們還將相機適配到 NVIDIA Jetson Orin 內核中。
＊The lens on this camera is not interchangeable, if you need to replace the lens, please contact sales in advance!／本相機鏡頭不可更換，如需更換鏡頭，請提前聯絡銷售！＊
★KERNEL CAMERA DRIVER USED
This camera relies on kernel drivers to work – one kernel version, one camera driver. Note on supported Nvidia Jetson Boards and Jetpack versions, please refer to Supported JetPack Version for Different NVIDIA Jetson Platforms to ensure compatibility.
★ SUPPORTED PLATFORM DISCLAIMER
This camera is specifically designed for the official NVIDIA® Jetson™ Developer Kit by default and does not support third-party carrier boards.
【Features】：
- 〔More Than HD〕： This camera adopts 1/4” 8 Megapixel IMX219 sensor for sharp image, Max. still resolution is 3280 x 2464 pixels.
- 〔Wider Angle of View〕： This camera module has 220°(H) wide-angle M12 Lens, which provides a much wider Field of View compared to the stock lens on V2 camera module.
- 〔IR Sensitivity〕： Integral IR filter, visible light only; Focal Length: 0.76 mm
【Specification／規格】：
- Sony 8MP IMX219 Sensor
- Optical Format: 1/4 inch
- Sensor image area：3.68 x 2.76 mm (4.6 mm diagonal)
- Pixel Size：1.12 µm x 1.12 µm
- Frame Rate: 30fps@8MP, 60fps@1080p, 120fps@720p
- Frame Rate (NVIDIA Orin NX): 3280x2464@21fps
- Data Format: RAW8/RAW10
- Lens part number:M32076M20 M12鏡頭
- EFL: 0.76mm 焦距
- F.NO: 2.1
- Focus Type： Fixed Focus 定焦
- View Angle: 220(H) 220度水平視角
- Interface: MIPI CSI-2 2-lane/4-lane
- IR Sensitivity：Integral IR-cut Filter, visible light only／集成紅外濾光片，僅可見光（沒夜視）
- Camera Board size：25 x 24 mm
Peaking Current：300mA
【Video Modes】：
NVIDIA Jetson Orin NX/Orin Nano/AGX Orin:
3280x2464@21fps,
3280x1848@28fps,
1920x1080@30fps,
1640x1232@30fps,
1280x720@60fps
