產品說明0
新型號：CANBUS-THERMO-2CH (SK1494) ※本產品原廠代理從國外進口，有些交期較長，下訂前請詢問！
2 Channel CAN-Bus Thermocouple Interface K-Type
2 通道 CAN 總線熱電偶接口 K 型（不包括熱電偶探頭。）
新型號：CANBUS-THERMO-2CH (SK1494)
ＰＳ．Thermocouple probes not included.／不包括熱電偶探頭。
This board provides a two channel CAN-Bus thermocouple K-type interface. It can read a temperature from -270 to +1250 oC depending on probe used. The CAN ID can be configured with the on board DIP switches and sample rate can be configure at 0.5 or 1 second interval.
該板提供了一個雙通道 CAN-Bus 熱電偶 K 型接口。根據所使用的探頭，它可以讀取從 -270 到 +1250 oC 的溫度。CAN ID 可以通過板載 DIP 開關進行配置，採樣率可以以 0.5 或 1 秒的間隔進行配置。
Features
- Two channel K-type thermocouple inputs
- -270 to +1250 ºC input range (probe dependent)
- 0.25 ºC resolution
- 0.5 or 1 second sample rate
- 6v to 16v input voltage range
- Reverse voltage polarity protection
- Selectable CAN baudrate via dip switches. 125, 500, 1000kbps
- Selectable CAN ID via dip switches
- UART output
- SWD/JTAG header
- LED indicator
